Home  >  Compound / Metallurgical / Inverted & More  >  Trinocular Compound Microscope 40x~1500x with LED light + Kohler Kit

Trinocular Compound Microscope 40x~1500x with LED light + Kohler Kit
Click to enlargeTrinocular Compound Microscope 40x~1500x with LED light + Kohler Kit

Availability: Usually ships the same business day

TKL-931Regular price: $999.99Sale price: $549.99
USB Digital Camera::

Kohler Trinocular Compound

Kohler Trinocular Compound

Kohler Trinocular Compound

This versatile microscope is designed for professionals. The TKL931 microscope is equipped with 10X and 15X eyepieces, and four high quality DIN standard objectives. A Kohler device and a 3W LED light provide safe and even bright illumination.



Features & Specifications





Model

TKL931

Total Magnification

40X, 60X, 100X, 150X, 400X, 600X, 1000X and 1500X

Eyepieces

A pair of widefield 10X/18
A pair of widefield 15X/11

Objectives

Achromatic DIN standard 4X/0.10, 10X/0.25, 40X/0.65 (spring), 100X/1.25 (spring, oil)

Viewing Head

Trinocular, 30 Inclined, 360 rotatable
Hinged interpupillary distance adjustment: 55 - 75 mm
Diopter ring on left eyepiece tube

Nosepiece

Revolving, quadruple

Stage

Double-layer mechanical stage, range 40 mm x 78 mm, dimension 156 mm X 135mm

Condenser

Abbe NA1.25 w/ iris diaphragm and filter holder
Condenser focus control lever for quick adjustment

Aperture
Diaphragm

Iris diaphragm, attached on the condenser

Focusing Mechanism

Coaxial coarse and fine focusing knobs on left side.
Fine focusing knob on right side.
Tool-free tension adjustment

Illumination

Transmitted, 3W LED light (equivalent to 30W halogen)
Kohler illumination device
Variable intensity

Power Supply

100-240V, 50/60Hz, 0.5A

Dimension

12-3/16" x 7-7/8" x 17" (31 cm x 20 cm x 43.3 cm)

Net weight

12 lb 9 oz (5.72 kg)





Packing List:



  • Microscope body
  • Microscope viewing head
  • Photo tube
  • A pair of 10X eyepieces
  • A pair of 15X eyepieces
  • 4 DIN objectives: 4X, 10X, 40X and 100X
  • Immersion oil
  • Blue color filter
  • Powr cord
  • Dust cover
  • Extra fuse
  • Allen key
